Isolated DC-DC Power Modules |Medium Voltage 24V Input Isolated DC-DC Power Modules ATMV24V50V160MA1

Home > High/Medium/Low Voltage Power Supplies > Medium Voltage Power Supplies > Medium Voltage Isolated DC-DC Power Modules > 24V Input Isolated DC-DC Power Modules

Medium Voltage 24V Input Isolated DC-DC Power Modules ATMV24VPN100V75MA2

Availability: In Stock

FEATURES

●Wide Input Power Voltage Range: 18V to 36V ●Output Voltage: ±100V ●Max. Output Current: ±75mA ●High Efficiency: 75% ●Output Ripple Voltage: ±1% @20MHz ●Isolation Voltage: 1500VDC ●Output Short-Circuit Protection: Automatic Recovery ●Full Aluminum Housing for Complete Shielding ●Operating Temperature Range: −40°C ~ +85°C ●100 % Lead (Pb)-free and RoHS Compliant

APPLICATIONS

⚫ Sustaining Ion Pumps ⚫ Spectral Analysis ⚫ Electrophoresis ⚫ Particle Accelerator ⚫ Capillary Electrophoresis ⚫ Piezo Devices ⚫ Photo Multiplier Tubes ⚫ Avalanche Photo Diodes
